| MODEL | VACUUM | clamping forec | injection volume | mold opening system | ||
| INJ | V | TON | CC | RT | FIFO | FILO |
| have/not |
| clamping forec(TON) | injection volume(c.c) | Heating Platen size(mm) | injection pressure(kg/cm²) | injection Temp Crontral() | motor | daylight(mm) | stoke of main ram | screw diameter | barrel diameter |
| 100 | 500/1000 | 405x430 | 1900 | 2set | 15HP | 350-450 | 350 | ψ35/40 | ψ65/80 |
| 200 | 1000/1500 | 550x550 | 1900 | 2set | 20HP | 400-550 | 450 | ψ40 | ψ80 |
| 250 | 2000/2500 | 650x650 | 1900 | 2set | 20HP | 400-550 | 450 | ψ40 | ψ80 |
| 350 | 2500/3000 | 700x700 | 1900 | 2set | 25HP | 400-550 | 450 | ψ40/50 | ψ80/100 |
| 500 | 3000/4000 | 850x850 | 1900 | 2set | 25HP | 400-550 | 450 | ψ50 | ψ100 |
| Special Specifications | Please Contact Us | ||||||||
- Application
Suitable for existing transfer molds, and hot runner injection molds. - Advantages For Running A Transfer Mold On This Injection Machine
Material Saving-Saving rubber compound and leaving no transfer pad or flash.
Labor Saving-No need to manually load and prepare the rubber blank or pad.
An existing transfer mold can be adapted to this injection machine esaily by making an additional cold runner injection plate - Advantages For Running A Hot Runner Injection Mold On This Injection Machine
Accurate Material Dosing-Giving Higher injection pressure for each mold cavity.
Tool Cost Saving-No need to make new cold runner mold.
Usage of Existing Mold-The existing hot runner mold can be adapted on this injection machine easily by removing the current hot runner and keeping the current injection points.
